25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed

Certification
China Shenzhen KHJ Technology Co., Ltd certification
China Shenzhen KHJ Technology Co., Ltd certification
I'm Online Chat Now

25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed

25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed
25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed 25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed 25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed 25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed

Large Image :  25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: TS630L
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: For samples 1-3 days and for mass order depends on your QTY.
Payment Terms: L/C, T/T
Supply Ability: 50000 rolls per month

25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed

Description
Product Name: TS630L Backing Thickness: 0.100 ±0.002 Mm
Total Tape Thickness: 0.145±0.005mm Tensile Strength: ≥105(KN/M)
Elongation: ≥120% Tack: ≥12(J.DOW/#)
High Light:

25N Thermal Conductive Adhesive Tape

,

0.145mm Thermal Conductive Adhesive Tape

,

25N thermal conductive tape

25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed



Polyester film backed pressure-sensitive adhesive tape TS630L



TS630L is a polyester film backed pressure-sensitive adhesive single-sided coated thermal release tape. It has a high initial adhesion and easily is peeled off by heating under a certain high temperature.



Features And Benefits:

1. Adhesive strength becomes almost “zero” by heating and can be removed without damaging substrates.

2. Substrates can be processed by temporarily fixing pressure sensitive adhesive face to the stage.

3. Provides a high processing accuracy since substrates are kept in a fixed position.

4. Three types (rolls, labelers and sheets) are available.

5. Environmentally friendly since no cleaning is required for substrates.



Thermal Conductive Adhesive Tape Properties:

Item   Typical Value Test Method
    Metric
Backing 0.075mm /
Total Thickness 0.145±0.005mm /
Tack   ≥12(J.DOW/#)
Adhesion Before heating ≥25N/25mm



GBT 2792-2014

  After heating   0
Tensile Strength ≥105(KN/M) GBT 30776-2014
Elongation ≥120% GBT 30776-2014



Construction:

25N Pressure Sensitive Thermal Conductive Adhesive Tape Polyester Film Backed 0



Application:

TS630L is a unique thermal release tape that is excellent for high temperature applications. Adhesion is virtually eliminated by heating to release temperature, available in single and double sided. Polyester film, acrylic adhesive with PET liner.



Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



Why buy from us instead of buying from other suppliers?

1. Good location and convenient transportation.

2. SGS certification.

3. Advanced production and processing equipment, environmentally friendly and reliable products.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
