High Initial Peeling Strength UV Release Tape 6.6mil polyester surface

High Initial Peeling Strength UV Release Tape 6.6mil polyester surface
High Initial Peeling Strength UV Release Tape 6.6mil polyester surface High Initial Peeling Strength UV Release Tape 6.6mil polyester surface High Initial Peeling Strength UV Release Tape 6.6mil polyester surface High Initial Peeling Strength UV Release Tape 6.6mil polyester surface

Large Image :  High Initial Peeling Strength UV Release Tape 6.6mil polyester surface

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: E1-UV388G
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: For samples 1-3 days and for mass order depends on your QTY.
Payment Terms: L/C, T/T
Supply Ability: 50000 rolls per month

High Initial Peeling Strength UV Release Tape 6.6mil polyester surface

Description
Product Name: E1-UV388G Elongation: ≥520%
Tensile Strength: ≥4(KN/M) Backing: 0.14mm
Peeling Strength Before UV: 8~10N/25mm Peeling Strength After UV: 0.05~0.15N/25mm
High Light:

6.6mil UV Release Tape

,

5.6mil backing UV Release Tape

,

6.6mil uv resistant electrical tape

High Initial Peeling Strength UV Release Tape 6.6mil Polyester Surface



UV release tape E1-UV388G with high initial peeling strength



E1-UV388G is a high performance product coating UV adhesive on the surface of polyester. It has high initial peeling strength. Low adhesion after UV irradiation and no residue after peeling off.



Features And Benefits:

1. High initial adhesion.

2. Low adhesion after UV curing, easy to separate.



Properties:

Item Typical Value
Imperial Metric
Backing 5.6mil 0.14mm
Total Thickness 6.6±0.2mil 0.165±0.005mm
Peeling strength Before UV 1.8~5.7lbs/in 8~10N/25mm
After UV 0.11~0.36lbs/in 0.05~0.15N/25mm
Tensile Strength ≥22.85lbs/in ≥4(KN/M)
Elongation ≥520% ≥520%
Surface Resistance 106~8ohms 106~8ohms



Construction:

High Initial Peeling Strength UV Release Tape 6.6mil polyester surface 0

Application:

1. Wafer, component, glass cutting and grinding process cutting.

2. 3D glass bonding process, component packaging transfer.

3. Soft lithium battery protection, metal and anti-static protection.



Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



Competitive advantages of our factory:

1. Very competitive price and high quality control.

2. Timely delivery.



What are our advantages?

1. Professional tape manufacturer for nearly 20 years.

2. Gold supplier.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
