Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes

Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes
Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes

Large Image :  Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: E2-UV381D
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: For samples 1-3 days and for mass order depends on your QTY.
Payment Terms: L/C, T/T
Supply Ability: 50000 rolls per month

Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes

Description
Product Name: E1-UV381D Backing Thickness: 0.100 ±0.002mm
Total Tape Thickness: 0.120±0.005mm Elongation At Break: ≥45%
Peeling Strength Before UV: >6N/25mm Peeling Strength After UV: 0.3N/25mm
High Light:

UV Releasing ESD Adhesive Tape

,

Polyester ESD Adhesive Tape

,

ESD Polyester Tapes

Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes



Double-coated anti-static high temperature UV-Releasing adhesive polyester tape E2-UV381D



E2-UV381D is a high performance product coating UV adhesive on the surface of polyester. It has high initial peeling strength. Low adhesion after UV irradiation and no residue after peeling off.



Features and Benefits:

1. High initial adhesion.

2. Low adhesion after UV curing, easy to separate.



Properties:

Item

Typical Value Metric

Test Method

Test Method

Backing 0.100mm /
Total Thickness 0.120±0.005mm /
Peeling strength Before UV 6N/25mm GBT 2792-2014
                            After UV 0.3N/25mm
Tensile Strength ≥8(KN/M) GBT 30776-2014
Elongation ≥45% GBT 30776-2014
Surface Resistance 10 6~9 ohms /

Adhesive Side Resistance



10 6-9 ohms /



Construction:

Double Coated ESD Adhesive Tape UV Releasing Polyester Tapes 0



Application:

1. Wafer, component, glass cutting and grinding process cutting.

2. 3D glass bonding process, component packaging transfer.

3. Soft lithium battery protection, metal and anti-static protection.



Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



What are our advantages?

1. Professional tape manufacturer for nearly 20 years.

2. Gold supplier.

3. Provide samples and best service.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
