High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape

Certification
China Shenzhen KHJ Technology Co., Ltd certification
China Shenzhen KHJ Technology Co., Ltd certification
I'm Online Chat Now

High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape

High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape
High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape

Large Image :  High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: E2-MA311
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Poly Bag+ Carton
Delivery Time: 1 Week
Payment Terms: L/C, T/T
Supply Ability: 10000 M2/Day

High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape

Description
Product Name: E2-MA311 Adhesion To Steel: 2~5N/25mm
Total Tape Thickness: 0.11±0.002mm Elongation At Break: ≥5%
Static Discharge: <100V Tensile Strength At Break: ≥2(KN/M)
High Light:

Single Side ESD Adhesive Tape

,

Crepe ESD Adhesive Tape

,

ESD Crepe Paper Masking Tape

High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape



Anti-static tape based with crepe paper tape E2-MA311 with good adhesion



E2-MA311 is a anti-static tape based with crepe paper with good adhesion.It not only has no residue after being removed, but also has low electrification when pasted and removed.



Features And Benefits:

1. Low electrostatic discharge at unwind.

2. RoHS Compliant..

3. No residue after removal.



Properties:

Item Crepe Paper Masking Tape Typical Value
Total Thickness 0.11±0.002mm
Adhesion to Steel 2~5N/25mm
Tensile Strength ≥2(KN/M)
Elongation ≥5%
Surface resistance Back 106-11ohms
Adhesive 106-11ohms
Static Discharge ≤100V



Construction:

High Adhesion ESD Adhesive Tape Single Side Crepe Paper Masking Tape 0



Application:

The product can be applied to various environments with anti-static requirements, such as fixing, connecting and packaging of electronic manufacturing.



Storage

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



Why buy from us instead of buying from other suppliers?

1. Good location and convenient transportation.

2. SGS certification.

3. Advanced production and processing equipment, environmentally friendly and reliable products.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
