Captone Tape

Product Details

Place of Origin: China

Brand Name: khj

Certification: TDS

Model Number: IH852

Payment & Shipping Terms

Minimum Order Quantity: 10

Price: 5$/PCS

Delivery Time: 7 day

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 100000

Get Best Price
Product Details
High Light:
Product Description

IH852 is a polyimide film-backed Captone Tape with superior heat resistance and insulation properties, ideal for high temperature environments.




Features for Electrical Insulation and Clean Removal Without Residue. 280 for 5 minutes Resistance with excellent Tensile Strength & Elongation. RoHS Compliant.



Application-Masking printed circuit boards during wave solder or solder dip processes; masking contacts during spray painting, powder coating & solder coating processes. Bundling transformers, motors, batteries & electronic components together for insulation purposes.


captone tape


Item Typical Value Test Method
Imperial Metric
Backing 1.0mil 0.025mm /
Total Thickness 2.2mil 0.055±0.005mm /
Tack / ≥26(J.DOW/#) /
Adhesion to Steel 0.91~1.37lbs/in 4~6N/25mm GBT 2792-2014
Tensile Strength ≥20lbs/in ≥3.5(KN/M) GBT 30776-2014
Elongation ≥45% ≥45% GBT 30776-2014



>4000V >4000V /




536℉ 280℃ /



Captone Tape 2 Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct


Captone Tape 3 Shelf life: 12 months from the date of manufacture when stored in initial



Precaution Reminder

Captone Tape 4 Surface should be clean, dry, free of dust, oil or other contaminants. Captone Tape 5 Proper pressure required by roller, hand or press when applying. Captone Tape 6 Avoid repeat sticking to prevent adhesion decrease.








Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
