KHJ 11 series cover tape extender, Applicable to all size(8/12/16/24/32/44/56/72/88mm) carrier tapes

Product Details

Place of Origin: Guangdong, China

Brand Name: KHJ

Certification: RoHS

Model Number: SMS11 series

Payment & Shipping Terms

Minimum Order Quantity: 1 Bag

Price: Negotiable

Delivery Time: 3-5 workdays

Payment Terms: L/C, T/T

Supply Ability: 10000㎡/day

Get Best Price
Product Details
High Light:

12mm SMT Splice Tape

,

24mm SMT Splice Tape

,

8mm Smt Cover Tape Extender

Product Name:
SMS11 Series
Material:
PET
Adhesive:
Acrylic
Size:
4mm,8mm,12mm,16mm,24mm,32mm,44mm,56mm,72mm,88mm
Color:
Yellow, Black, Blue,Green
Peeling-off Force:
(N/25mm) By Angle Of 180 Degree≥15
Product Name:
SMS11 Series
Material:
PET
Adhesive:
Acrylic
Size:
4mm,8mm,12mm,16mm,24mm,32mm,44mm,56mm,72mm,88mm
Color:
Yellow, Black, Blue,Green
Peeling-off Force:
(N/25mm) By Angle Of 180 Degree≥15
Product Description

splice tape

Multiple product types:


1. Double-sided splicing tape;
2. Single sided splicing tapes;
3. Splice tape with copper buckle;
4. Sealing lead tape;
5. Sharp corner splicing tapes;
6. Aluminum foil splicing tapes;
7. Machine splicing tapes;
8. Splicing tapes with holes;

Support 8mm-72mm carrier tape, at the same time have splicing pliers, splice cutter, splicing cart and other SMT splicing tool.



KHJ 11 series cover tape extender, Applicable to all size(8/12/16/24/32/44/56/72/88mm) carrier tapes



11 series cover tape extender is used for jointing carrier tapes in the SMT process. It is made of tapes and polyester film and release paper, and the tape is with superior adhesion.



Features And Benefits:

1. Used as cover tape extender,make full use of surplus materials.

2. Strong adhesion, safe and reliable.

3. Easy to operate and with high efficiency.

4. Applicable to all SMT machines.



Application:

Used for SMT process,to solve SMT carrier tape connection problems.



Properties:

P/N Qty Carrier Tape Size Color ESD NO ESD





SMS1104/08/12/16/

24/32/44/56/72/88





500/250Pcs/Box





4mm/8mm/12mm/16mm/24mm/

32mm/44mm/56mm/72mm/88mm

C
B
G
M
L



Storage condition:
Temperature: 20℃-30℃
Ralative Humidity(RH): 45%-65%
Shelf-life: One year



Keywords:SMT cover tape extender, SMT anti-static cover tape extender



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
