ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness

Certification
China Shenzhen KHJ Technology Co., Ltd certification
China Shenzhen KHJ Technology Co., Ltd certification
I'm Online Chat Now

ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness

ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness
ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness

Large Image :  ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: IH890S
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: 3~5days after payment done
Supply Ability: 10000 square meters/day

ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness

Description
Product Name: IH890S Adhesion To Steel: 2-3.5N/25mm
Total Tape Thickness: 0.035±0.005mm Tensile Strength At Break: ≥5(KN/M)
Temperature Resistance:: 260℃ *5 Mins Backing Thickness: 0.025mm
High Light:

Polyimide High Temperature Resistant Tape

,

1.38mil High Temperature Resistant Tape

,

kapton polyimide tape

ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness



Non-silicone polyimide film tape-IH890S heat resistant adhesive tape with good heating resistance



IH890S is a polyimide film backed Acrylic adhesive tape with excellent heatresistance and insulation properties.



Features And Benefits:

1. Resistant high temperature up to 260℃.

2. Good Adhesion ,No residue after removal.

3. Excellent anti-aging ability, long shelf life.



kapton polyimide tape Properties:

Item Typical Value



Test Method

Imperial Metric
Backing 1.0mil 0.025mm /
Total Thickness 1.38±0.2mil 0.035±0.005mm /
Adhesion to Steel 0.45~0.79lbs/in 2~3.5N/25mm GBT 2792-2014
Tensile Strength ≥28lbs/in ≥5(KN/M) GBT 30776-2014
Elongation ≥45% ≥45% GBT 30776-2014

Maximum Operating

Temperature

500℉ 260℃*5min No residue after removal





Construction:

ODM Polyimide Film High Temperature Resistant Tape 1.38mil Thickness 0



Application:

Masking or protecting residue sensitive areas on printed circuit boards during high temperature operations such as wave soldering and solder reflow.



Storage

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



Competitive advantages of our factory:

1. Very competitive price and high quality control.

2. Timely delivery.

3. Accept small orders.



What are our advantages?

1. Professional tape manufacturer for nearly 20 years.

2. Gold supplier.

3. Provide samples and best service.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
