Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness

Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness
Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness

Large Image :  Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: IH899BF
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: 3~5days after payment done
Payment Terms: L/C, T/T
Supply Ability: 10000 square meters/day

Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness

Description
Product Name: IH899BF Backing Thickness: 0.025mm
Thermal Conductivity(w/mk): 0.2±0.05 Color: Amber
Elongation At Break: >20% Upmost Temperature: 260℃
High Light:

Polyimide Heat Resistant Adhesive Tape

,

0.042mm Heat Resistant Adhesive Tape

,

Polyimide thermal resistant tape

Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness



High elongation heat resistant acrylic polyimide tape - IH899BF heat resistant tape with high adhesion



IH899BF is double-stretched Polyimide film as coated acrylic pressure-sensitive adhesive. Which has low adhesion and good high temperature resistance. covered with blue release film for easy die-cutting and forming.



Features And Benefits:

1. Low adhesion to make sure no any residue after removal.

2. Excellent heat resistance performance.

3. ROHS Compliant.



Properties:



Test Item Test Value Test Method
Backing thickness(mm) 0.025±0.003 Micrometer
Release liner thickness(mm) 0.075±0.003 Micrometer
Total thickness(mm) (Without Release liner) 0.042+0.003/-0.002 Micrometer
Color Amber /
Peeling Strength (gf/25mm) 40-70 GBT 2792-2014
≦180(High temperature climb peel force) GBT 2792-2014
Maximum use temperature (℃) 200℃ Using condition :200℃/2H for steel plate &FPC ,no residue and no wrinkle after cooling




Construction:

Acrylic Polyimide Heat Resistant Adhesive Tape High Adhesion 0.042mm Thickness 0



Application:

Ideal for surface protection of flat materials such as FPC (PCB) during high-temperature processing, or temporary protection.



Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 6 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Be kept away from heat and fire sources;

2. The surface of the object should be clean, dry, and free of oil or other pollution;

3. Due to the use of pressure-sensitive adhesives, sufficient pressure must be applied when pressing; if the pressing is not sufficient, it will have an adverse effect on the characteristics and appearance of the product.

4. Cannot be used outdoors, to avoid the influence of outdoor weather, there will be residual glue left on the substrate when the tape is removed.



What are our advantages?

1. Professional tape manufacturer for nearly 20 years.

2. Gold supplier.

3. Provide samples and best service.

4. Good production capacity and fast delivery.



Notes:

Above data is measured by laboratory standards. The actual data may be different due to the user's use conditions and methods. It is recommended to test the product before use.
