KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series

KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series
KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series

Large Image :  KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: SMS20 series
Payment & Shipping Terms:
Minimum Order Quantity: 1box
Price: Negotiable

KHJ20 series 8 Holes Designed Single Splice Tape Acrylic PET 8mm Series

Description
Product Name: SMS20 Series Material: PET
Adhesive: Acrylic Size: 8mm
Color: Yellow Certification: SGS
High Light:

8mm Single Splice Tape

,

12mm Single Splice Tape

,

8mm film splicing tape

8 Holes Designed Single Splice Tape Acrylic PET 8mm Series



Professional SMT special splice tape with 8 holes designed for Universal Juki Sanyo Machines



20 series splice tape are used in jointing carrier tapes for Universal Juki Sanyo machine in SMT process, This splice tape is made by our produced polyester (PET) material with superior adhesion.



Features And Benefits:

1. 8 holes designed for easy alignment and reliable jointing.

2. Jointed carrier tape without tape covered in the middleto reduce feeder jam rate.

3. Available for 8mm carrier tapes.

4. Applicable for Universal Juki Sanyo machines.



Application:

SMS‐20XXC series splice tape are used in jointing carrier tapes for Universal Juki Sanyo machines.



Properties:

P/N Specification Application Package
SMS-2008 (1.65/4.5/4.2)x40mm For 8mm 500pcs/box


Technical Data:





No

Item Standard
1 Peeling-off force (N/25mm) ≥15
2 Retaining (H/25*25mm) time >100
3 Tensile strength at break (N/25mm)

>4.0



How to use:

Ideal application environment: 20-28℃,after sticking it onto carrier tapes, press it tightly at different locations on carrier tapes.This product is not proposed to be used as SMT cover tape extenders when SMT machine starts working.



Storage condition:
Temperature: 20℃-30℃
Ralative Humidity(RH): 45%-65%
Shelf-life: One year



Why buy from us instead of buying from other suppliers?

1. Good location and convenient transportation.

2. SGS certification.

3. Advanced production and processing equipment, environmentally friendly and reliable products.

4. Good reputation and after-sales service team.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
