KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process

Best Products
Certification
China Shenzhen KHJ Technology Co., Ltd certification
China Shenzhen KHJ Technology Co., Ltd certification
I'm Online Chat Now

KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process

KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process
KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process

Large Image :  KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: SMS21 series
Payment & Shipping Terms:
Minimum Order Quantity: 1box
Price: Negotiable

KHJ21 series Custom size 4mm SMT special splice tape used in jointing 4mm carrier tapes only in SMT process

Description
Product Name: SMS21 Series Size: 4mm
Certification: RoHS Color: Yellow
Material: PET
High Light:

4mm SMT Splice Tape

,

Custom SMT Splice Tape

,

4mm Splice Carrier Tapes

Acrylic Adhesive PET 4mm Splicing Tape For SMT Process



21 series splice tape are used in jointing 4 mm carrier tapes only in SMT process, This splice tape is made by our produced polyester (PET) material with superior adhesion.



Features And Benefits:

1. Jointed carrier tape without tape covered in the middleto reduce feeder jam rate.

2. Available for 4mm carrier tapes only.

3. Applicable for all SMT machines except sensitive machine.



Application:

SMS‐21XXC series splice tape are used in jointing carrier tapes for 4mm carrier tape only.



Properties:

P/N Specification Application Package
SMS-2104c   For 4mm 500pcs/box



Technical Data:

No

Item Standard
1 Peeling-off force (N/25mm) ≥15
2 Retaining (H/25*25mm) time >100
3 Tensile strength at break (N/25mm)

>4.0



How to use:

Ideal application environment: 20-28℃,after sticking it onto carrier tapes, press it tightly at different locations on carrier tapes.This product is not proposed to be used as SMT cover tape extenders when SMT machine starts working.



Storage condition:
Temperature: 20℃-30℃
Ralative Humidity(RH): 45%-65%
Shelf-life: One year



Competitive advantages of our factory:

1. Very competitive price and high quality control.

2. Timely delivery.

3. Environmentally friendly products.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
