ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip

ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip
ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip

Large Image :  ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip

Product Details:
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: SMS16 Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Bag
Price: Negotiable
Delivery Time: 3-5 workdays
Payment Terms: L/C, T/T
Supply Ability: 10000㎡/day

ESD SMT Carrier Tape 8 / 12 / 16 / 24mm With Clip

Description
Product Name: SMS16 Series Material: PET
Adhesive: Acrylic Size: 8mm,12mm,16mm,24mm Etc
Color: Black Certification: RoHS
High Light:

ESD SMT Carrier Tape

,

SMT Carrier Tape With Clip

,

SMT Splice Tape With Clip

ESD Black SMT Carrier Tape Release Paper 8/12/16/24mm With Clip SMS16 Series



Professional ESD black SMT special splice tape with clip designed for Panasonic Siemens Fuji Machine



SMS‐16XXMC series splice tape are used for jointing carrier tapes in the SMT process. It is made of tape, release paper,PVC and single clip. It has good adhesion.



Features And Benefits:

1. Splice tape+clips designed for more reliable jointing.

2. Sense by metal or color, Ideal Panasonic, Siemens, Fuji Machine.

3. Available for 8mm,12mm,16mm,24mm, etc carrier tapes.

4. Applicable for Panasonic,Siemens,Fuji machine.



Application:

SMS‐16XXMC series splice tape are used in jointing carrier tapes for Panasonic Siemens,Fuji machine, whose sensor detects by metal or color. Splice tape+clips designed for more reliable jointing.





Structure:

                                   ESD Black SMT Carrier Tape Release Paper 8/12/16/24mm With Clip SMS 16 Series 0

Technical Data:

No Test content Test value
1 Peeling-off force(N/25mm)by angle of 180 degree ≥15
2 Retaining (H/25*25mm)(H/25*25mm) ≥100
3 Tensile strength at break(KN/M) >4



How to use:

Ideal application environment: 20-28℃,after sticking it onto carrier tapes, press it tightly at different locations on carrier tapes. This product is not proposed to be used as SMT cover tape extenders when SMT machine starts working.



Storage Condition:

Temperature: 20℃-30℃

Ralative Humidity(RH): 45%-65%

Shelf-life: One year



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
