Temperature Resistant Crepe Paper Tape 5.2mil Thickness Rohs Approved

Product Details

Place of Origin: Guangdong, China

Brand Name: KHJ

Certification: ROHS

Model Number: MH310C

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiable

Packaging Details: Plastic bag + carton

Delivery Time: For samples 1-3 days and for mass order depends on your QTY.

Supply Ability: 50000 rolls per month

Get Best Price
Contact Now
Specifications
High Light:

5.2mil Crepe Paper Tape

,

Rohs Crepe Paper Tape

,

5.2mil crepe tape

Product Name:
MH310C
Total Tape Thickness:
0.13±0.01mm
Adhesion To Steel:
7~8N/25mm
Temperature Resistance:
200℃
Tensile Strength:
≥2(KN/M)
Elongation:
≥5%
Product Name:
MH310C
Total Tape Thickness:
0.13±0.01mm
Adhesion To Steel:
7~8N/25mm
Temperature Resistance:
200℃
Tensile Strength:
≥2(KN/M)
Elongation:
≥5%
Description
Temperature Resistant Crepe Paper Tape 5.2mil Thickness Rohs Approved

khjkhj emailkhj workshop

Temperature Resistant Crepe Paper Tape 5.2mil Thickness Rohs Approved

Crepe paper based tape with super temperature resistant property MH310C



MH310C is crepe paper based tape with super temperature resistant properties, which is ideal for masking items during high temperature process.



Features And Benefits:

1. Resistant high temperature up to 200℃.

2. RoHS Compliant.

3. Strong adhesion, no residue after removal.



Crepe Paper Tape MH310C Properties:

Item Typical Value
Imperial Metric
Total Thickness 5.2mil 0.13±0.01mm
Adhesion to Steel 1.6~1.8lbs/in 7~8N/25mm
Tensile Strength ≥11.43lbs/in ≥2(KN/M)
Elongation ≥5% ≥5%
Temperature Resistance 392℉ 200℃



Construction:

Temperature Resistant Crepe Paper Tape 5.2mil Thickness Rohs Approved 3

Application:

Mainly used in the protection of the gold finger and other jacks on the circuit board during the wave soldering process of the circuit board.

Temperature Resistant Crepe Paper Tape 5.2mil Thickness Rohs Approved 4



Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.



Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.



Competitive advantages of our factory:

1. Environmentally friendly products.

2. Various designs.



Why buy from us instead of buying from other suppliers?

1. SGS certification.

2. Good reputation and after-sales service team.



Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
