Shenzhen KHJ Technology Co., Ltd marketing@khj.cn 86-0755-28102935
Product Details
Place of Origin: Guangdong, China
Brand Name: KHJ
Certification: RoHS
Model Number: E2-IC268A
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Plastic bag + carton
Delivery Time: For samples 1-3 days and for mass order depends on your QTY.
Payment Terms: L/C, T/T
Supply Ability: 50000 rolls per month
Product Name: |
E2-IC268A |
Static Discharge (Removal From Roll): |
<100V |
Unwind Force: |
>0.4N/25mm |
Total Tape Thickness: |
0.085±005mm |
Adhesion To Steel: |
>0.5N/25mm |
Backing Thickness: |
0.070mm |
Product Name: |
E2-IC268A |
Static Discharge (Removal From Roll): |
<100V |
Unwind Force: |
>0.4N/25mm |
Total Tape Thickness: |
0.085±005mm |
Adhesion To Steel: |
>0.5N/25mm |
Backing Thickness: |
0.070mm |
Anti Static PP Film Backed Acrylic Adhesive Tape Roll Silicone Free OEM ODM
Anti-static PP film backed acrylic adhesive tape roll E2-IC268A with silicone free
E2-IC268A is an anti-static PP film backed acrylic adhesive tape roll, it is specially used for cleaning various surface dust.
Features And Benefits:
1. No need to cut by blade.
2. No glue residue.
3. Low electrostatic discharge at unwinding.
4. Silicone free.
Properties:
| Item | Typical Value | Test Method |
| Backing | 0.070mm | / |
| Total Thickness | 0.085±0.005mm | / |
| Tack | 6# | GBT4852-2002 |
| Adhesion to Steel | >0.5N/25mm | GB/T 2792-2014 |
| Unwind Force | >0.4N/25mm | GB/T 2792-2014 |
| Surface Resistance | 10 6-10 ohms | ANSI STM4.1-2017 |
| Adhesion Resistance | 10 7-11 ohms | ANSI STM4.1-2017 |
| Static Discharge (Removal from roll) | <100V |
/ |
Construction:
Application:
It is widely used in PCB automatic clean machine to remove PCB surface particle before next processes. This rolls is also necessary for PCT, LCD, LED, electronics and other industry’s surface clean.
Storage:
1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.
2. Shelf life: 12 months from the date of manufacture when stored in initial packing.
Precaution Reminder:
1. Surface should be clean, dry, free of dust, oil or other contaminants.
2. Proper pressure required by roller, hand or press when applying.
3. Avoid repeat sticking to prevent adhesion decrease.
Competitive advantages of our factory:
1. Environmentally friendly products.
2. Accept small orders.
What are our advantages?
1. Provide samples and best service.
2. Good production capacity and fast delivery.
3. SGS certification.
Notes:
Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
