| Brand Name: | KHJ |
| Model Number: | UV392F |
Description
UV392F is an UV adhesive tape with high initial tack, after UV irradiation,the stickiness of the surface is greatly reduced, and it can be easily peeled off.
Construction
Features
Application
| Item | Typical Value | Test Method | ||
| Imperial | Metric | |||
| Backing | 6mils | 0.15mm | ASTM D1005 | |
| Total Thickness | 6.8mil | 0.17mm | ASTM D1005 | |
| Adhesion to Steel | Before UV | 2.87-3.75lbs/in | 13-17N/25mm | GBT 2792-2014 |
| After UV | 0.02lbs/in | 0.1N/25mm | ||
| Tensile Strength | Horizontal | 20Mpa |
GBT 30776-2014
|
|
| Vertical | 20Mpa | |||
| Elongation | Horizontal | 500% | ||
| Vertical | 500% | |||
* Conditions of UV irradiation: UV irradiation energy is 500-600mj/cm2, dominant wavelength is 365nm.
Storage
Precaution Reminder
Notes
Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
